Features:
LeCroy, Probe, Passive, 500 MHz, 5mm, 10:1, 10 MOhm
- A Teledyne LeCroy ÷10, 500 MHz, 10 MΩ, Passive Probe
- Bandwidth 500 MHz
- Maximum Input Voltage 500 V
- Input Resistance 10 MΩ
Input Capacitance 9.5 pFPassive probes are the standard probe provided with most oscilloscopes. Typical passive probes provide a 10:1 attenuation and feature a high input resistance of 10 MΩ. This high input resistance means that passive probes are the ideal tool for low frequency signals since circuit loading at these frequencies is minimized. Passive probes are designed to handle voltages of at least 400V, some as high as 600V. Teledyne LeCroy passive probes feature an attenuation sense pin which tells the oscilloscope to scale the waveforms automatically requiring no user input.
Технические характеристики
| Manufacturer | Teledyne LeCroy |
|---|---|
| Condition | Used |
| Voltage | 500 V |
| Frequency | 500 MHz |
