Description
Features and Benefits
- Transfers take place in as little as 15–60 min
- Minimal buffer requirements save money
- Capacity to transfer up to four Mini-PROTEAN precast or handcast gels, or three Criterion gels
- Single-step locking system allows simple, speedy setup
- Platinum-coated titanium anode plate electrodes and stainless-steel cathode plate electrodes provide consistent and reliable transfers, durability, and long life
- Extra plastic templates required by other semi-dry blotters to prevent electrode short circuits are unnecessary
- Safety cover breaks the electrical current when lifted, preventing electrical shock
Applications and Uses
- Western blotting
- Nucleic acid transfer
- Northern and Southern blot transfers in 10–35 min
- Transfer of DNA and RNA using the unique agarose gel semi-dry blotting support frame
Features:
- Maximum gel size (W x L), cm: 24 x 16
- Buffer requirement, ml: 200
- Gel capacity: 4 Mini-PROTEAN precast or handcast gels, 3 Criterion gels, 1–3 PROTEAN II gel sandwiches
- Recommended power supply: PowerPac HC (High Current)
- Dimensions (W x L x H), cm: 37 x 24 x 11
- Weight, kg/lb: 3.6/7.9
