Series QL short-stroke cylinders are available in different bore sizes and are designed to cover a wide range of application needs, from light duties in packaging or assembly to the demanding requirements of handling components for woodworking. The low weight of the aluminium body and the compact design makes this cylinder range quick and easy to install, even in confined or awkward spaces. The Series QL is available in double acting, magnetic and non-magnetic designs. A full range of accessories such as standard, large and narrow mounting feet enhance the applicability and usability of the range. BENEFITS: Compact design Low weight Easy installation SECTORS: Packaging Assembly Food & Beverage Rubber & Plastics Woodworking
Технические характеристики
CharacteristicsTypepneumaticTechnologymagnetic pistonConfigurationdouble-actingMaterialstainless steel, aluminumApplicationsfood, handlingOther characteristicscompact, lightweight, short-strokeStroke
Min.: 5 mm (0.197 in)
Max.: 300 mm (11.811 in)
Pressure
Min.: 1 bar (14.5 psi)
Max.: 10 bar (145 psi)
Rod diameter
Min.: 12 mm (0 in)
Max.: 50 mm (2 in)
Ambient temperature
Min.: 0 °C (32 °F)
Max.: 80 °C (176 °F)
