A typical ultra-low friction cylinder is generally used as an oscillating or tensioning cylinder. It is single acting, in the sense that compressed air is normally fed into one of the two chambers only. An external force acts on the other side. Metal Work’s ultra-low friction cylinder is designed as a double-acting one, which means the compressed air can be fed into the rear or either the front chamber. They are built to comply with ISO 15552 and are available with or without a magnet. Supplied with a series 3 barrel. A through-rod version is not available. These cylinders are always non-cushioned. The gaskets are made of NBR. A full range of accessories is available Quantity per package: 0 Minimum order quantity: 0 Unit of measure: items SEAL: NBR gaskets
Технические характеристики
CharacteristicsTypepneumaticTechnologywith piston rodConfigurationdouble-actingNormsISO 15552Other characteristicslow-friction, oscillating, ATEXStroke
Max.: 1,200 mm (47.244 in)
Min.: 1 mm (0.039 in)
Pressure
10 bar (145 psi)
Bore
Max.: 125 mm (4.92 in)
Min.: 32 mm (1.26 in)
Ambient temperature
Max.: 80 °C (176 °F)
Min.: -10 °C (14 °F)
