The M-RS-40 Metric Rotation Stage provides precision rotation of components for laboratory, production, or industrial OEM applications. This aluminum stage rotates 360° in a precision bored bushing. By tightening a thumb screw on the side of the stage, the platform is tangentially driven by the precision actuator. The M-RS40 includes a BM11.5 micrometer. The mounting hole pattern for the M-RS40 is compatible with other 40 mm size components. A tapped hole is provided on the side for mounting this rotation stages vertically on a post
Технические характеристики
- Coarse Travel 360°
- Fine Travel 10°
- Diameter 40 mm
- Load Capacity 50 N
- Sensitivity 16 arc sec
- Thread Type M3 and M6
- Graduations 2°
- Vernier 0.2°
- Included Actuators BM11.5
