The Velocity TLB-6702 Widely Tunable Laser features a 407-412 nm tuning range and 4 mW of free space output power at 411 nm. It offers up to 5 nm/s tuning speed. The TLB-6700 series is a complete redesign of our well established Velocity laser series. The worlds most advanced tunable diode laser system, Velocity offers complete single mode tuning across its entire output spectrum with no mode hops and closed loop wavelength position control.
The integrated wavelength monitoring system allows the user to dial up a wavelength with 0.01 nm accuracy and scan across all or part of the tuning range. Weve enlarged the drop tested and shock proof cavity housing, added more powerful temperature control, and introduced our unique Magnetic Damping to the 6700 Velocity. This means we can now bring you higher power output with an even further reduced linewidth. Thats more power with even greater precision. An optional 35 dB isolation and fiber coupling kit is available for the TLB-6702.
Includes TLB-6700-LN controller.
Технические характеристики
- Mode-Hop Free Fine Tuning Range >120 GHz (65 pm)
- Mode-Hop Free Wide Tuning Range 407-412 nm
- Free Space Output Power 4 mW @ 411 nm
- Fiber-Coupled Output Power N/A
- Tuning Speed 5 nm/s
