P/N: UCPK206-20 Key Specs
Item
PILLOW BLOCK BEARING, LOW BASE, SET SCREW, BORE 31.75 MM
OEM
Tritan
OEM #
UCPK206-20
Condition
New OEM Original
Returnable
No
Bearing Material
AISI 52100 Steel
Bearing Type
Mounted Bearing Unit
Bolt Hole Size
7/16 / M12
Bore Diameter Millimeters
31.75
Construction
Cast Iron
Dynamic Load Rating (N)
4384
Insert
UC206-20
Internal Radial Clearance
0.013 — 0.033
Locking Type
Set Screw
Maximum Temperature
250 F
Mounting Hole Center Millimeter
121
Mounting Surface To Centerline Of Shaft (Mm)
39.69
Number Of Bolts
2
Overall Height (Mm)
80
Overall Length (Mm)
160
Overall Width (Mm)
38.1
Static Load Rating (N)
2540
Width Millimeters
38.1
