P/N: UCFLU-1MFG1 Key Specs
Item
FLANGE BEARING 2-BOLT BALL 1 BORE
OEM
NTN
OEM #
UCFLU-1MFG1
Condition
New OEM Original
Returnable
No
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Shell Alvania #3 or NLGI #3 Equivalent
Bolt Hole Center-to-Center
3 57/64 in
Bolt Size
7/16 in
Bore Dia.
1 in
Dynamic Load Capacity
3,150 lb
Finish
Black Oxide
Mounted Bearing Item
2-Bolt Flange Bearing
Overall Height
1 17/32 in
Overall Length
4 29/32 in
Overall Width
2 3/4 in
Series
Standard Duty with Food Grade Solid Lubrication, Set Screw
Shaft Locking Type
Set Screw
Static Load Capacity
1,770 lb
Temp. Range
-10 Degrees to 95 Degrees C
