P/N: TDR782XDXA-12D Key Specs
Item
H7848 TIME DELAY RELAY 12VDC 3A 4PDT 0.1 SEC.
OEM
APC / American Power Conversion
OEM #
TDR782XDXA-12D
Condition
New OEM Original
Returnable
No
Adjustment Method — Timer
Dip Switch, Rotary Knob
Base Type — Plug In Relay
Square
Body Depth — Relay
1 in
Body Height — Relay
2.3 in
Body Width — Relay
0.8 in
Coil Volts
12V DC
Contact Form — Relay
4PDT
Contact Material
Silver Alloy
Electrical Connection
Socket
Function — Timing Relay
On Delay
Hz — Electrical
50 Hz, 60 Hz
Item — Relay
Single Function Timing Relay
Max Time Setting — Timer
4 day 4 hr
Min Time Setting — Timer
0.1 sec
Mounting — Relay
Plug In
Number of Pins — Relay
14
Overall Height — Relay
2.44 in
Power Consumption — Relay
1.5 W
Socket
1EGP7, 1EGP8, 1EGR1, 2A584
Standards
CE, UL
Status Indicator
LED
