P/N: T173 Key Specs
Item
24HR 120V DPST TIMERSKIPADAY
OEM
Intermatic
OEM #
T173
Condition
New OEM Original
Returnable
No
Amps
40
Contact Form
DPST-NO
Contact HP @ 120V
2
Contact HP @ 240V
5
Day Skipper
Yes
Depth
3 in
Description/Special Features
Snap-out Timing Mechanism, Up to 12 On/Off Settings Per Day, Manual On/Off Override does not Alter Program, Furnished with a Maximum of 12 Trippers
Enclosure Type
Steel
Extra Trippers
11Z965
Finish
Metal Enclosure has Gray Enamel
Height
7-13/16 in
Max On/Off Cycles
12
Max Time Setting
23 hr.
Min Time Setting
1 hr.
Mount
Screw
NEMA Rating
1
Nominal Max Time Setting
24 hr
Number of Poles
2
Number of Trippers Included
2
Type
24-Hour
Voltage
120VAC
Width
5 in
