P/N: SSM1A312BDR Key Specs
Item
SOLID STATE RELAY 4-32VDC INPUT/CONTROL
OEM
APC / American Power Conversion
OEM #
SSM1A312BDR
Condition
New OEM Original
Returnable
No
Body Depth — Relay
3.3 in
Body Height — Relay
3.45 in
Body Width — Relay
0.71 in
Case Color
Black
Contact Form — Relay
SPST-NO
Heat Sink
Integral
Includes
Integrated Heat Sink
Input or Control Voltage
4 to 32V DC
Item — Relay
Solid State Relay
Max Output Amps Without Heat Sink
12
Mounting — Relay
DIN Rail
Output or Controlled Voltage Range
48 to 600V AC
Overall Height — Relay
3.56 in
Standards
CSA, IEC 60950-1, IEC 61000, IEC 62314, REACH, UL
Switch Type
SCR
