P/N: RAYCMLTK Key Specs
Item
FIXED MOUNT IR TEMP SENSOR -4 TO 932F
OEM
Fluke Networks
OEM #
RAYCMLTK
Condition
New OEM Original
Returnable
No
Ambient Temperature Range
32 Degrees to 160 Degrees F
Diameter
0.75 in
Environmental Applications
IP 65 (NEMA-4)
Impedance
100 ohm
Includes
(2) Mounting Nuts and Instructions
Loop Resistance
50 kilohm
Manufacturers Warranty Length
2 yr
Repeatability
+/-0.5% of Reading or +/-3.5 Degrees F (Whichever is Greater)
Response Time
150ms
Sensor Accuracy
+/-1.5%
Sensor Cable Length
3 ft 4 in
Sensor Current Rating
10mA
Sensor Emissivity
0.1 to 1.1
Sensor Item
Fixed Mount Infrared Temperature Sensor
Sensor Length
3.7 in
Sensor Measurement Temperature Range
-4 Degrees to 932 Degrees F
Sensor Output Type
K Thermocouple
Sensor Power Source
24V DC
Sensor Spot Size and Distance
0.46 in @ 6 in
Spectral Response
8 to 14uM
Thread Size
3/4-16 UNF 2A
