P/N: NCDMB056-0050 Key Specs
Item
AIR CYLINDER 1/2 IN STROKE 3.19 IN L
OEM
Speedaire
OEM #
NCDMB056-0050
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
9/16 in
Air Cylinder Mount
Nose
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Stainless Steel
Bore Dia.
9/16 in
Cushion Type
None
Cylinder Action
Double Acting
Cylinder Type
Round
End Cap Material
Aluminum
Finish
Hard Coat Anodized
Magnetic Piston
Yes
Max. Pressure
250 psi
Mount
Nose
Nose Mount Thread
7/16-20 UNF
Overall Length
3.19 in
Piston Material
Magnetic
Piston Rod Material
Chrome Plated Carbon Steel
Port Size
#10-32 UNF
Rod Dia.
0.197 in
Rod Thread Length
0.5 in
Rod Thread Size
#10-32 UNF
Single Acting/Double Acting
Double Acting
Stroke
1/2 in
Temp. Range
40 Degrees to 140 Degrees F
Tie Rod Material
N
Tube Material
Stainless Steel
