P/N: KS7S2042HM30#&VAC Key Specs
Item
SANITARY TRANSDUCER 30 IN HG VAC TO30PSI
OEM
Ashcroft Inc.
OEM #
KS7S2042HM30#&VAC
Condition
New OEM Original
Returnable
No
Accuracy — Transmitter
+/-1.00%
Compatible With
Any Process Compatible with 316 Stainless Steel
Electrical Connections — Transmitter
4 Pin Hirschmann Style A DIN 43650 A Connector
Housing
Stainless Steel
Includes
Instructions
Loop Resistance
Dependent on Loop Supply Voltage
Manufacturers Warranty Length
1 yr
Max Pressure (PSI)
60 psi
NEMA Rating
4X
Operating Temperature — Transmitter
-20 Degrees to 180 Degrees F
Output — Transmitter
4 to 20mA DC
Power Required — Transmitters
9 to 36V DC
Process Connection Size — Transmitter
2 in
Process Connection Type — Transmitter
Triclamp
Range Units — Transmitter
in Hg/psi
Range Values — Transmitter
30 to 0 to 30
Thermal Error
+/-.04% per / Degrees F from -20 Degrees to 168 Degrees F
Transmitter Type
Compound Transmitter
Wetted Materials — Transmitters
316L Stainless Steel
Wiring Entry — Transmitter
1/2 in FNPT
