P/N: HGA261252 Key Specs
Item
CIRCUIT BREAKER 125A 2P 600VAC HG
OEM
Square D
OEM #
HGA261252
Condition
New OEM Original
Returnable
No
AC Voltage Rating
600V AC
Amps
125 A
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
I-Line
Circuit Breaker Type
Standard
DC Voltage Rating
250/500/600V DC
Depth
4.8 in
For Use With
I Line Panelboards
Frame Size
150A/HG
Height
9.73 in
High Amp Trip Setting
1,700 A
Instantaneous Trip
Fixed
Low Amp Trip Setting
900 A
Max Air Rating
65kA at 240V AC
Max Operating Temperature
104 Degrees F
Max Wire Size
3 AWG
Min Wire Size
14 AWG
Number of Poles
2
Phase
1
Phase Connection
AC
Series
HG
Standards
CE, CSA, IEC, UL listed
Terminal Connection
Lug
Trip Type
Thermal Magnetic
Width
2.94 in
