P/N: G661 Key Specs
Item
EXPLOSION PROOF MOTOR, 56T17G5313, 3/4HP, 208-230/460V, 1800RPM, 3PH, EPFC
OEM
Marathon Motors
OEM #
G661
Condition
New OEM Original
Returnable
No
60 Hertz Kw
0.56
60 Hertz Rpms
1800
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
2.9-3.0/1.5
Frame
56
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
3/4
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
56T17G5313
Motor Rpm 60Hz
1800
Mounting
Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Across the Line
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
208-230/460
Weight
30
