P/N: A2XBM0242C25#G Key Specs
Item
D3841 EXPLOSION PROOF TRANSDUCER 0 TO 5 PSI
OEM
Ashcroft Inc.
OEM #
A2XBM0242C25#G
Condition
New OEM Original
Returnable
No
Accuracy — Transmitter
+/-0.25%
Compatible With
Any Process Compatible with 316 Stainless Steel
Electrical Connections — Transmitter
3 ft Cable
Housing
304 Stainless Steel
Includes
Instructions
Loop Resistance
Dependent on Loop Supply Voltage
Manufacturers Warranty Length
1 yr
Max Pressure (PSI)
10 psi
NEMA Rating
7 and 9
Operating Temperature — Transmitter
-40 Degrees to 257 Degrees F
Output — Transmitter
4 to 20mA DC
Power Required — Transmitters
12 to 30V DC
Process Connection Size — Transmitter
1/4 in
Process Connection Type — Transmitter
MNPT
Range Units — Transmitter
psi
Range Values — Transmitter
0 to 5
Safety Rating — Transmitter
Class I, Div. 1 and 2, Groups A, B, C, D, Class I and II, Div 1 and 2, Groups E, F, G
Thermal Error
+/-2% (-4 Degrees to 185 Degrees F)
Transmitter Type
Explosion Proof Pressure Transmitter
Wetted Materials — Transmitters
316L Stainless Steel
Wiring Entry — Transmitter
1/2 in FNPT
