P/N: 8300C Key Specs
Item
ELECTRIC STRIKE FIRE RATED 12/24VDC
OEM
HES — Hoffman Engineered Systems
OEM #
8300C
Condition
New OEM Original
Returnable
No
Bolt Throw
1/2 in, 5/8 in
Door Frame Type
Metal/Wood
Faceplate Depth
1-11/16 in
Faceplate Height
4-7/8 in
Faceplate Width
1-1/4 in
Failure Mode
Fail Safe or Fail Secure
Finish
Satin Stainless
Fire Rated
3 hr
For Use With
Cylindrical Locksets
Grade
1
Includes
(2) Face Plates, Mounting Hardware, Strike Body
Input Voltage
Electric Strike, Medium-Duty, 12/24V DC
Material
Stainless Steel
Performance
Medium-Duty
Pull Force
1,500 lb
Standards
ANSI/BHMA A156.31, ASTM-E152, CAN4-S104, Grade 1, NFPA 80-07, NFPA-252, UBC-7-2-94, UL 1034 Listed, UL 10C Listed
Strikes
500,000 Cycles
