P/N: 4Z720 Key Specs
Item
SPEED REDUCER C-FACE 56C 87 1
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4Z720
Condition
New OEM Original
Returnable
No
Bearings
Ball
Bore Dia.
5/8 in
Duty
Standard
Finish
Powdered Epoxy Paint
Frame
56C
Gear Material
Hardened and Ground Steel
Gear Type
Helical
Housing Material
Cast Aluminum
Input RPM
1,750
Lubrication
Klubersynth UH1 6-460
Max. Input HP
0.3 hp
Max. Output Torque
998 in-lb
Nominal Output RPM
20
Nominal Ratio
87:1
Number of Stages
1
Output Shaft Dia.
1 in
Output Shaft Height
4 7/8 in
Output Torque @ 1/3 HP
998 in-lb
Output Torque @ 1/4 HP
748 in-lb
Overhung Load
1,192 lb
Pinion Material
Hardened Steel
Rotation
Forward/Reversible
Seal Type
Double Lip
Shaft Orientation
Parallel/Inline
Single/Double Output/Universal
Single Output
Solid/Hollow Output Shaft
Solid
Speed Reducer Type
C-Face
Standards
AGMA
