P/N: 216NT1 Key Specs
Item
HIGH TEMPERATURE INDUSTRIAL FAN PHASE 1
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
216NT1
Condition
New OEM Original
Returnable
No
Air Flow
5,500 cfm
Air Velocity @ 10 Ft.
910 fpm
Air Velocity @ 20 Ft.
580 fpm
Air Velocity @ 40 Ft.
240 fpm
Air Velocity @ 60 Ft.
155 fpm
Amps
2.6/5.2
Assembly Required
No
Bearing Type
Ball
Blade Diameter
20 in
Blade Material
Aluminum
Color
Gray
Depth
13 1/4 in
Environmental Applications
High Ambient
Fan Mounting Location
Ceiling, Post, Wall
Features
Mounting Bolts, Conduit Box
Guard Material
Steel
Height
23 in
Height Adjustment
Fixed Height
Hz
60
Includes
High Ambient Air Circulator, Mounting Bracket
Max. Ambient Temp.
140 Degrees F
Motor Design
Permanent Split Capacitor
Motor Enclosure
Totally Enclosed Air-Over
Motor HP
1/2 hp
Motor Insulation
Class B
NEMA Plug Configuration
Hardwired
Number of Blades
3
Number of Speeds
1
Oscillation
Non-Oscillating
Phase
1
Shaft Dia.
1/2 in
Sound Level
76dBA
Standards
UL, cUL, OSHA
Thermal Protection
Automatic Reset
Voltage
115/230VAC
Watts
600
Wheeled Base
Stationary
Width
23 in
Wire Guard Finish
Powder Coated
