Мультиметр UNI-T UT71E

The UT71E is a multimeter with a very good price/quality ratio. The model offers a 40,000-count display and precision up to 0.05% for DC voltages.

The multimeter offers True-RMS and can perform two measurements per second at the 40,000-count resolution. The meter can store up to 100 samples, which can be retrieved later.

The Bar Graph is a useful feature of this multimeter, which updates 10 times per second, and shows how a measured value changes during the measurement. This graph has 40 segments and therefore only shows a rough image.

In addition to the 40,000-count main display, the UT71E also has two secondary displays with 4,000-counts. These can display other useful information at the same time as the main display. For example, the phase angle and VA values are displayed during a power measurement, or the frequency during an AC voltage measurement.

The UT71E comes with a USB cable that allows you to connect the multimeter to a computer. With the included software, the multimeter can be used for multiple applications. This way data can be logged, or a Pass/Fail evaluation can be done.

Furthermore, the UT71E comes with an accessory that allows the multimeter to measure power from a wall socket. This allows you to perform power measurements of all equipment with a plug..

This product is covered by a 3-year warranty and can therefore be used with confidence for a longer period of time.

Specifications Measuring range and precision Max. DC Voltage1000 V (&plusmn,0.05%+5) Max. AC Voltage1000 V (&plusmn,5%+30)

45 Hz ~ 100 kHz Max. DC Current10 A (&plusmn,0.15%+15) Max. AC Current10 A (&plusmn,2.5%+20)

45 Hz ~ 10 kHz Max. resistance40 M (&plusmn,1%+40) Power0 W — 2500 W (&plusmn,2%+50) Max. capacitance40 mF (&plusmn,1.2%+20) Frequency40Hz — 400 MHz (&plusmn,0.01%+8) Temperature -40 ºC ~ 1000 ºC (&plusmn,1%+30) Display count 40,000 (4¾ digit) + 2x 4000 + 40 segment bar graph Connectivity USB Power supply 9 V battery Safety norms CAT III 1000 V

CAT IV 600 V Dimensions 205 x 95 x 45 mm Weight 406 g Accessories

The UNI-T UT71E comes with:

• Battery
• Test leads
• USB cable
• Carrier bag
• Temperature probe (K-Type)
• Power measurement cable (Euro plug)

Options

Optionally, the meter be expanded with the following Bluetooth module in order to display and log measurements on a smartphone.
