IQ3 Pro Range multi-turn electric actuators can be used for isolation or regulating duties of up to 60 starts per hour. IQ3 Pro Range actuators can be supplied as watertight or explosion-proof. Direct torque output range from 14 Nm (10 lbf.ft) to 3,000 Nm (2,200 lbf.ft). With the addition of second stage gearboxes, multi-turn output torque up to 43,000 Nm and quarter-turn up to 1,000,000 Nm is available. Enhanced sealing and maintenance access. All new design with updated visual appearance. Absolute position measurement with naturally redundant position sensor. Best-in-class display, communications, diagnostics and HMI. Configurable using Bluetooth® or infrared. Designed to support asset management. ‘Future Proofed’ to allow all embedded software to be upgraded in the field. Insight 2 provides enhanced product data management.
Технические характеристики
CharacteristicsTypeelectricMovementmulti-turnOther characteristicsexplosion-proof, with handwheel, smart, remote-controlledTorque
Max.: 3,000 Nm (2,212.69 ft.lb)
Min.: 14 Nm (10.33 ft.lb)
