The Matsuura LS-160 5-axis machining center offers unerring accuracy & the highest quality surface finish in the shortest cycle time possible. Ultra-high speed, unparalleled high accuracy & optimized state-of-the-art machining performance are supplied as standard with the LS-160. Available as a single-table machine or twin pallet, with scalable options tailored to your unmanned production.
Технические характеристики
Specifications
| Specification | Detail |
|---|---|
| X Axis Travel | 19.68 in. |
| Y Axis Travel | 9.84 in. |
| Z Axis Travel | 11.81 in. |
| A-Axis Travel | -125~+125 degrees |
| C-Axis Travel | 360 |
| Table Working Surface | Ø,3.93 in. |
| Loading Capacity | 44 lb. |
| Max. Work Size | Ø,6.29 x H9.05 in. |
| Spindle Speed | 400 ~ 40,000 min-1 |
| Max. Spindle Motor Torques | 24,000 min-1 |
| Tool Storage Capacity | 10 pcs. |
| Max. Tool Diameter | Ø,1.81 in. |
| Max. Tool Length | 5.90 in. |
