CMM-M series Manual Coordinate Measuring machine is extensively used in the field of machinery, automobile, aviation, metal and high precision tool manufacturing. It is required for CAD, CAE and CAM in reverse engineering. Various models include CMM-554M, CMM-665M, CMM-564M, CMM-685M, CMM-574M, CMM-6105M, CMM-584M. It operates using RENISHAW MH 20i probing system and rational DMIS software. It is provided with Air bearing guidance, moving bridge structure, space accuracy Accuracy of MPEE = 4.0 + L／200 µm and offers resolution of 0.5 µm. Dimensions include 1.0 x 1.1 x 2.2, 1.14 x 1.1 x 2.4, 1.0 x 1.2 x 2.2, 1.14 x 1.3 x 2.4, 1.0 x 1.3 x 2.2, 1.14 x 1.5 x 2.4, 1.0 x 1.4 x 2.2. Machine weighs 700／770／840／910 900 ／1040 ／1180 kg.
Технические характеристики
CharacteristicsControlmanually-controlledStructurebridgeApplicationsfor gears, for the aeronautical industry, CAD/CAM, for CAD, for automotive applications, for guide rails, for machineryProbe typemulti-sensorOther characteristicshigh-precisionX travel
500 mm (20 in)
Y travel
Max.: 800 mm (31 in)
Min.: 500 mm (20 in)
Z travel
400 mm (16 in)
