Description
The Magnaflux QB2-Plus provides a quantitative verification of Quick Break function and measures the duration of a magnetizing shot. The QB2-Plus can verify the correct function of AC, HWDC, and FWDC equipment, and verify Quick Break function on 3-phase FWDC units. Shot time and Quick Break voltage are shown alternately on the LCD display after each reading.
Specifications Compliance: ASTM E709, ASTM E1444, ISO 9934, ASTM E3024
Технические характеристики
Specs
Product Specifications
Shot Time Range | 0.40 to 5.00 seconds |
| Shot Time Accuracy | +/- 0.02 seconds |
| Quick Break (3-phase only) | 0 to 30 V +/- 0.2 V |
| Display | Dot-matrix LCD |
| Power Supply | DC 9V Battery |
