The 9063-XZ Gothic-Arch XZ Translation Stage uses stainless-steel construction and thumbscrew locks to offer the ultimate in stability and rigidity. Gothic-arch bearings offer the smooth motion of ball bearings but high stiffness and repeatability over the 25.4 mm X and Z travel range. The 65 x 65 mm platform features 2-56, 8-32 and 1/4-20 mounting holes. The unique gothic profile provides four points of contact (rather than two) so that the load and momentum are more evenly distributed. Side-mounted micrometer clamps minimize the overall footprint. These stages are compatible with our goniometers and rotation stages.
Технические характеристики
- Axes of Travel X, Z
- Maximum Stage Travel 25.4 mm
- Centered Normal Load Capacity 173 N
- Vertical Axial Load Capacity 35 N
- Roll 10 arc sec
- Yaw 20 arc sec
- Material Stainless Steel
- Bearings Gothic-Arch Bearings
- Platform Size 65 x 65 mm
- Thread Type 2-56, 8-32, and 1/4-20
- Recommended Adjustment Screw 9302
- Recommended Micrometer 9356
- Recommended Piezo Actuator 8303
