CONEX-TRB6CC is a compact DC servo actuator integrated with a CONEX-CC controller that provides 6 mm travel in a slim, 16 mm diameter housing, and is recommended for motorizing 561 series linear stages, and 481 and RS65 rotation stages. TRB actuators can replace micrometers which are used a wide variety of linear stages, mirror mounts, and OEM applications.
The CONEX™ controller comes with a simple and intuitive GUI and is conveniently accessible via USB. It comes with a USB cable and a CONEX-PS-CB for daisy-chaining modules. The power supply is ordered separately. For OEM applications, an optional retainer to secure the USB and power cables is available.
Технические характеристики
- Stage Type TRB Linear Actuator
- Travel Range 6 mm
- Push Force 90 N
- Maximum Speed 2 mm/s
- Minimum Incremental Motion 0.10 m
- Absolute Accuracy, Typical ±,2.0 m
- Absolute Accuracy, Guaranteed ±,3.0 m
- Uni-directional Repeatability, Typical ±,0.05 m
- Uni-directional Repeatability, Guaranteed ±,0.25 m
- Bi-directional Repeatability, Typical ±,0.13 m
- Bi-directional Repeatability, Guaranteed ±,0.75 m
- Drive Type DC servo
- Drive Mechanism Rolled lead screw
- Drive Screw Pitch 1 mm
- Reduction Gear 1:67.5
- Limit Switches Optical switches, both ends
- Origin Optical, at lower limit
- Origin Repeatability ±,2 m
- Feedback Motor mounted rotary encoder, 1024 cts/rev.
- Encoder Resolution 0.01447 m
- Control Loop Floating point digital PID loop with velocity and friction feedforward, 2 kHz servo rate
- Display Two-color LED
- Programming 40+ intuitive, 2 letter ASCII commands.
- Weight 0.21 kg
- Power Requirements 24 VDC, 8 W
- Cable Length 1.5 m
- Computer Interfaces USB
- Controller Dimensions 93.2 x 53 x 23 mm
- MTBF 10 000 h (25N load, 10% duty cycle)
- Compliance RoHS 3, CE
