MTE series resistance and capacitance standards are designed for calibration of ohmmeters, LCR meters and insulation testers. Alternatively, MTE standards can be used as transfer standards, keeping traceability between primary and secondary laboratories. MTE standards come in four terminal configurations to fit every application. OPEN and SHORT standards for zero calibration of LCR meters as well as custom nominals and terminal configurations are available upon request. Specifications: Resistance: 100 mΩ — 10 GΩ, 0 — 20 kHz (± 0.005% / year) Capacitance: 10 pF — 100 uF, 20 Hz — 20 kHz (± 0.02% / year) Inductance: 100 mH — 1 kH, 100 Hz — 20 kHz, simulated by T-network circuit (± 0.05% / year)
Технические характеристики
CharacteristicsApplicationsfor LCR meter, for multimeters, for ohmmeterTypecalibration, impedance
