Description
The KROHNE OPTIWAVE 7400 C radar level meter is designed for use with liquids and pastes. It is specifically targeted at measuring the level of corrosive liquids in agitated tanks. Contact us for non-Ex applications with extremely high process temperatures (up to 1292°F), like molten salt in solar plants. This meter can also be used in long-range (up to 328ft) or fast moving (up to 196.85ft/min) process applications.
KROHNE OPTIWAVE 7400 C Radar Level Meter Industries
- Chemical market
- Oil & Gas
- Petrochemicals
- Power
- Steel
For toxic and dangerous products it is recommended that you select a METAGLAS second sealing barrier option, which allows you to remove electronics without unsealing the process.
Технические характеристики
Features
- 2-wire loop-powered level transmitter
- Distance & reflection primary measured values
- Level, volume, & mass secondary measured vales
- K-band 24 to 26 GHz
- ±0.8in (±2mm) accuracy
- Up to 1450 psig (100 barg) process pressure
- Polyester-coated aluminum housing
- One user interface for all applications
- 3-year warranty
