The HVM-S1R Vertical-Drive Industrial Mirror Mount is unlike any optical mount in its class. Its body is made entirely from stainless steel, allowing it to be exceptionally stable. The HVM-S1R is designed to hold 1” optics and is loaded from the rear. Adjustments are made via two top-accessible 100-TPI adjusters which are lockable. Two alignment pin holes are provided for keying the mounting position.
Технические характеристики
- Mechanism Kinematic
- Optic Diameter 25.4 mm
- Number of Actuators 2
- Actuator Locks Yes
- Adjustment Screw Thread 100 TPI
- Adjustments x, y
- Sensitivity x = 2.47 arc sec, y = 2.97 arc sec
- Angular Range ±3 °
- Optic Loading Rear
- Material Stainless Steel
- Drive Type Allen-Key, locking
- Thread Type 8-32 (M4) CLR
- Optical Axis Height 25.4 mm
- Optic Thickness 4-7 mm
