The U200-A ULTIMA® Clear Quadrant Mirror Mount offers unsurpassed functionality. This optical mount for 2 inch (50.8 mm) diameter optics does not include actuators. Thick front and rear plates and optimized, stiff springs improve the long-term stability and provide greater protection against vibrations. Hard carbide pads enable smooth, repeatable motion. A large array of optical mounting accessories is available for these mounts making ULTIMA a basic building block for many optical systems. Convenient clearance mounting holes on each of two sides are compatible with either 8-32 or M4 screws providing quicker, more precise, and more secure mounting. ULTIMA mounts can be mounted to posts for adjustable height or pedestal posts for a stable fixed height.
Технические характеристики
- Mechanism Kinematic
- Optic Diameter 50.8 mm
- Number of Actuators 0
- Adjustments z, x, y
- Actuator Orientation Right-handed
- Optic Loading Front
- Material Anodized Aluminum
- Drive Type Not Included
- Thread Type 8-32 (M4) CLR
- Optical Axis Height 34.9 mm
