Description
The Kobold KP46 explosion-proof pressure transmitter features Class 1, Division 1 and 2 hazardous location approval per CSA standard 30 and UL standard 1203. All Kobold KP46 explosion-proof pressure transmitters require a 10 to 28 VDC power supply and provide a 2-wire, 4 to 20mA analog output. Pressure is measured by the KP46 to within 0.25% best fit, straight line accuracy.
The Kobold KP46 explosion-proof pressure transmitter is available in pressure ranges from 0 to 50 PSIG up to 0 to 20,000 PSIG. Ranges up to 10,000 PSIG feature a 1/4 inch NPT process connection and 316L stainless steel wetter materials while ranges above 10,000 PSIG move to a 1/2 inch NPT connection and 17-4PH stainless steel. The KP46’s wetted materials feature corrosion resistance that complies with NACE MR0175.
Технические характеристики
Features
- Class 1, Div. 1 & 2 explosion-proof rating
- CSA standard 30 & UL standard 1203
- Pressure ranges up to 0 to 20,000 PSIG
- 4 to 20mA analog output
- 1/2 inch NPT conduit with 6 ft. wire leads
- Stainless steel wetted materials
- NACE MR0175 corrosion resistance
- NEMA 4X, IP66
