Application: | Type of pressure: relative pressure , Liquids and gases, Use in gases at pressures > 25 bar only after contacting the manufacturer ifm |
| Operating voltage: | 9.6…32 V DC |
| Ambient temperature: | -25…80 °C |
| Protection: | IP 68 / IP 69K |
| Output function: | 4…20 mA |
| Bursting pressure min.: | 850 bar |
| Materials (wetted parts): | stainless steel (303S22), ceramics, sealing: FPM (Viton), according to DIN 3869-14 |
| Shortcode: | PA-250-SBG14-A-ZVG/US/ /V |
| Connection: | M12 connector |
| Characteristics deviation : | < ± 0.25 (BFSL) / < ± 0.5 (LS) |
| Medium temperature: | -25…90 °C |
| Process connection: | G ? A / M5 I |
| Product Name: | PA3521 |
| SKU | HEKT9LWSRWXGM5 |
| Housing materials: | stainless steel 316L / 1.4404, FPM (Viton), PA, EPDM/X (Santoprene) |
| Measuring range: | 0…250 bar |
| Pressure rating: | 400 bar |
| Electrical design: | DC |
«
Buy IFM Electronic PA3521 with the best possible price and delivery terms on eltra-trade.com
