Available in two different nominal sizes, this check valve protects upstream equipment from possible damage caused by back pressure and prevents contamination. Thanks to its compact and space-saving design, the HyCheckValve can be ideally integrated into hydrogen refuelling stations. It is compatible with the HyValve range of valves, allowing you to benefit from the synergy effects of a single source. P or peace of mind, our hydrogen valves have been designed to provide long periods of operation and ease of maintenance and control Our HyCheckValve range will convince you with its high repeatability, maximum safety and outstanding reliability.
Технические характеристики
CharacteristicsFluidfor gasBodythreaded, screw-in, miniatureApplicationshigh-pressure, gas, for hydrogen, safety, for industrial applications, for the gas industry, for explosive atmospheresMaterialstainless steelOther characteristicscompact, in-line, horizontal, for high flow rates, top-mountedDN
Min.: 6 mm (0.236 in)
Max.: 8 mm (0.315 in)
Pressure
Min.: 0 bar (0 psi)
Max.: 1,000 bar (14,503.8 psi)
Temperature
Min.: -50 °C (-58 °F)
Max.: 85 °C (185 °F)
Flow rate
Min.: 1.16 us gal/min (4.39 l/min)
Max.: 2.66 us gal/min (10.07 l/min)
