The radial piston pump type R consists of valve-controlled pump elements arranged in star form around an eccentric. For large flow rates, up to 42 pump elements can be set up in 6 stars stacked one above the other. The pump elements’ output volume is merged to feed one or more pressure outlets. The radial piston pump types R and RG have a closed pump housing. It can consequently be used both as an external motor pump not installed in an oil tank or as an integrated version installed inside a hydraulic power pack’s tank (see D 6010 H). The radial piston pump type RG has plain bearings which have an extended service life. Features and benefits: Very high efficiency Can be run with low-viscosity media Fine delivery flow rate gradation Long service life Operation not dependent on direction of rotation Intended applications: Industrial hydraulics Testing machinery Lubrication systems Hydraulic tools
Технические характеристики
CharacteristicsTyperadial pistonOther characteristicscompact, modularPressure
Max.: 700 bar (10,153 psi)
Min.: 0 bar (0 psi)
Flow rate
Max.: 91.2 l/min (24.09 us gal/min)
Min.: 2.3 l/min (0.61 us gal/min)
Speed
1,450 rpm (9,111 rad.min-1)
Weight
Max.: 39.1 kg (86.2 lb)
Min.: 2.5 kg (5.51 lb)
Fluid temperature
Max.: 80 °C (176 °F)
Min.: -40 °C (-40 °F)
Power
Max.: 30 kW (40.8 hp)
Min.: 0.3 kW (0.4 hp)
