Flexible optical/electrical hybrid designs Easy to terminate Easy to clean ELIO® AQ adaptors enable the use of ELIO® fiber optic contact technology in all standard ARINC 600 and 38999 sIII connectors with insert cavities size 8. Many optical / electrical hybrid layouts are available. The flight proven ELIO® fiber optics termini are designed around a robust 2.5mm ceramic ferrule. The assembly is as easy an ST connector. The insertion and retention inside the connector is ensured by a bayonet locking mechanism without any special tool. The termini integrates a seal inside the rear boot, thus the connection is sealed from the rear side without a backshell or a grommet. The 8D ELIO® range covers layouts from 1 to 24 ways in all types of material shell. With the ELIO® AQ fiber optic adaptor, each cavity can be upgraded with the brand-new ELIOBEAM expanded beam ELIO® version. In the female insert, the termini are flushed to the insert surface, thus making easy the fiber optical end-face inspection and cleaning, compared to the traditional dust collecting socket design. The same termini part number can adapt tight or loose structure cable The fiber optic termini is keyed for better vibration withstanding and optical performances repeatability Multimode contact — Insertion Loss (IL):
Технические характеристики
CharacteristicsTypeopticalApplicationsfor fiber opticsConnector typefemale, bayonetOther characteristicshybrid
