42R-5L/H Series 3-Phase AC Inverter Duty Right Angle Hollow Shaft Gearmotor Application Information • Threaded mounting holes are located on both sides of gearhead. • We offer most standard models with either 230 VAC, 60Hz, 3-phase, or 230/460 VAC, 60 Hz, 3-phase winding options. Optional Accessories Die cast terminal box kit for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 0984] Die cast metric terminal box kit with terminal block for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 1984] Die cast terminal box kit for our 42R-FX stock gearmotors [model 0985] — Use model 0986 instead Shaft Kit 5L/H 5/8-inch / single shaft [model 0912] Shaft Kit 5L/H 5/8-inch / double shaft [model 0922] Cover Kit for 5L/H & GB/H Hollow Shaft Gearmotors [model 0951] Flange Mount Kit for 5L/H & GB/H Hollow Shaft Gearmotors [model 0956] Shaft Kit 5L/H 5/8-inch > 3/4-inch single shaft [model 0928] Base Mount Kit for 5L/H Hollow Shaft Gearmotors [model 0958] Large die cast terminal box kit for 34R, 42R, 48R, 42R-FX, 33A, 42A stock motors and gearmotors [model 0986] STANDARD FEATURES • Totally enclosed IP-20 rating. IP-44 with optional t-box kit installed. • Fan cooled for high output power. • Aluminum center ring and endshields for high thermal efficiency and light weight. • Unvented gearhousing for universal horizontal mounting. • Industrial lip type seals on motor and output shafts. • Ball bearings on output shaft for quietness. • Permanently lubricated gearing utilizing oil for long life. • Bronze gear for high shock load capability. • Hardened and ground worm for high strength and long life. • Hollow driveshaft for flexibility in mounting.
Технические характеристики
CharacteristicsMotor typeACTypewormShaft orientationright anglePower100 W…500 WVoltage 230 VTorque10 — 20 Nm, 5 — 10 NmProduct applicationsindustrialOther characteristicscompact, hollow-shaft, efficiency, high load capacity
