MFBS /MFB is a bellows type flexible coupling. The bellows allows eccentricity, angular misalignment, and end-play. Even if there is misalignment, the constant revolution is performed. Ideal for rotary encoder applications. There are two types of bellows: phosphor bronze type and stainless steel type. MFBS (set screw type, stainless steel) MFBS-C (clamping type, stainless steel) MFB (set screw type, aluminum hub) MFB-C (clamping type, aluminum hub) Application: Encoder
Технические характеристики
CharacteristicsTypeflexible, bellowsProduct applicationsfor shafts, for stepper motors, for servo motors, with encoderOther characteristicscompact, zero-backlash, misalignment correction, compensating, metal bellowsInstallation systemflangeTorque
Max.: 6 Nm (4.4254 ft.lb)
Min.: 0.5 Nm (0.3688 ft.lb)
Rotational speed
Max.: 52,000 rpm (326,725.64 rad.min-1)
Min.: 19,000 rpm (119,380.52 rad.min-1)
