FCLS is the most popular flexible shaft coupling in Japan that is compliant with JIS B 1452-1991 ‘Flexible Flanged Shaft Couplings’. Simple structure comprised of a flange and coupling bolts. Easy-to-mount. Bushings can be replaced just by removing coupling bolts. This makes maintenance and service easy. While it absorbs misalignment such as eccentricity and argument, it prevents noise by absorbing torsional vibration. It will not transmit thrust load, either. Two types are available: Cast Iron FCL and Carbon Steel FCLS. Spare parts -bolt & bush set -bush Optional Services -Bore and Keyway Additional Modification Service Please feel free to contact us for a quotation.
Технические характеристики
CharacteristicsTypeflexibleProduct applicationsfor pumps, for mixers, generator, industrial, blower, transmissionOther characteristicstorque, heavy-duty, disassemblable, high load capacityInstallation systemflangeTorque
Max.: 1,600 Nm (1,180.0994 ft.lb)
Min.: 33 Nm (24.3396 ft.lb)
Rotational speed
Max.: 6,000 rpm (37,699.11 rad.min-1)
Min.: 1,500 rpm (9,424.78 rad.min-1)
