EP Series 2 Pin Female Cable End Waterproof Connector (Mating to Male Panel Mount Connector) Contact Resistance≤10mΩ Insulation Resistance≥500MΩ Wire Gauge：0.5~2.5mm² Connection Method：Screw Clamp Housing Material：Engineering plastic Conductor Material：Copper alloy with Nickel plated Compliant with EN61984, GB/T34989, UL2238 Screw crimped, allows quick and easy wiring on site Spinning thread locked, firm connection Certified by TUV, CQC, UL, CE
Технические характеристики
CharacteristicsTypedata, electrical power supplyFormatSocket, overmoldedShapestraight, circularConnection typescrew-in, screw-locked, screw couplingSizeM23, M16Electrical characteristicspower, 2-pole, DC power, insulatedMaterialpolyamide, copper, nickel-platedProduct applicationstransmission, for cables, for power supplies, buildingDomainfor industrial applications, for military applications, for LED lighting, indoor/outdoorProtection classIP68Other characteristicswaterproof, with cable glandPrimary current
17.5 A
Voltage
450 V
Operating temperature
-40 °C, 85 °C (-40 °F)
