High precision loadcells for tension & compression, Recommended for all high precision measurements, test benches, laboratory tests, process control equipments. These loadcells are protected against accidental overloads in tension and compression. “S” load cells provide superior performance in compact packaging. Connected with ACRN measurement consoles. SEJ-Z Benefits Tension & compression Mechanical stop IP 50 Protection class Options Rings and hooks Rod ends Load button Longer length for cable Technical informations Output impedance — 390 Ohms Sensitivity — 2mV/V Construction — Body in aluminium and cover in stainless steel Power supply — 10 V (Max 15V) Combined linearity & hysteresis — 0,05% F.S (Full scale) Offset —
Технические характеристики
CharacteristicsTypecompressionFormS-beamOther characteristicshigh-precision, compact, aluminumRated force
Max.: 2,000 N
Min.: 10 N
Length
2 m (606)
