These deburring machines are simple and sturdy table machines equipped with a prismatic slide for efficient and precise machining of longitudinal edges down to smallest workpieces. ADVANTAGES • — Surface protecting precision chamfers up to 2 mm (no scratches on the workpiece) • — Easy operation • — Fast tool change • — Speed control for processing different materials • — Bearing supported sliding carriage for chatter-free milling Application — Burr-free chamfering of small precision parts from 1 mm thickness in almost polished precision — Universal for all materials and suitable for continuous operation — VHM-milling cutters for all non-hardened workpieces — CBN-grinding pencil for hardened steel — Diamond grinding pencil for carbide metal and glass The sliding carriage of the chamfering machine Speedy Prisma ensures that the workpieces keep scratch-free. Options — Extraction socket — Extraction device Features — Surface protecting precision chamfers up to 2 mm (no scratches on the workpiece) — Easy operation — Fast tool change — Speed control for processing different materials — Bearing supported sliding carriage for chatter-free milling Options • — Extraction socket • — Extraction device Delivery contents • — Allen key 2,5mm • — Prism cutter • — Operating manual
Технические характеристики
CharacteristicsOperationelectricTypestationary, deskApplicationsweld preparation, straight edges, edge milling machine, for metalOther characteristicswith sliding carriage, precisionPower
0.14 kW (0.19 hp)
Rotational speed
Max.: 30,000 rpm (188,495.56 rad.min-1)
Min.: 10,000 rpm (62,831.85 rad.min-1)
Chamfer width
Max.: 2 mm (0.1 in)
Min.: 0 mm (0 in)
Chamfer angle
45 °
