Depending on the application, products with a transport width of up to 2.5x the chain width can be conveyed here. As with the rest of the EURO-flex product family, upward and downward inclined sections can be overcome by means of chain links with different adhesive coatings or various individually adapted carriers. Simple assembly and disassembly is made possible by detachable screw connections which require no special tools. The EURO-flex 195 system is available in aluminium and hygienic stainless steel without slide rail. Assigned fields of application • Cosmetic • Healthcare Curve angle • Standard horizontal: Angle 15° to 180° | Radius 600 mm • Standard vertical: Angle 5 ° to 90° | Radius 600 mm • Other curve angles possible at any time Transitions • Frontend module active • Frontend module passive • Lateral • Lateral guiding belts Additional modules • Centring • Stopping • Separating • Pushing • Transfer • Grouping • Distributing
Технические характеристики
CharacteristicsTechnologychainFormhorizontal, vertical, spiralSectorfor the food industry, for the pharmaceutical industry, for the automotive industry, for the medical industryTransported productfood, for packagingOther characteristicsmodular, accumulation, stainless steel, aluminum, for large productsEffective width
190 mm, 195 mm (7 in)
