• mini-breakout installation cable U-VQ(ZN)H • bend insensitive fiber • UV-resistant, metal-free, waterproof and moisture-resistant • longitudinally water blocked and suitable for operation down to -40 °C • cable jacket: LSHF-FR (low smoke halogen free — flame retardant) • cable structure: tight buffered fibers (Ø 0.9 mm) in a common cable jacket •strain relief: glasroving elements • to be laid in tubes and cable ducts indoors and outdoors • applicable standards: EN 50173-1, ISO 11801 2nd edition, IEC 60794-2, IEC 60794-2-20, EN 187000 • fire behaviour: class Dca s1 d0 a1 acc. to EN 50399 (classification acc. to EN 13501-6) • variants: number of OS2 fibers: 4, 12, 24 • variants: number of OM5 fibers: 4, 12 • variants: number of OM4 fibers: 4, 12, 24 • variants: number of OM3 fibers: 4, 12, 24 • all available variants can be created with the configurator
Технические характеристики
CharacteristicsTypedataProtectionflame-retardant, UV-resistant, water-resistant, low-smoke, moisture-proofConfigurationtight structure, break-outApplicationsindoor/outdoor, for building cablingNormsIECOther characteristicsmultimode, halogen-free, ISOTemperature
Max.: 70 °C (158 °F)
Min.: -40 °C (-40 °F)
