Sick ACS36-L1K0-K01
Datasheet:
⟧W3⟧⟧W4⟧Article: 6052345⟧W5⟧⟧W6⟧Number of steps per revolution (max. resolution): 3.723⟧W7⟧⟧W8⟧Resolution per measuring step: 2.7 mV … 25, 1 mV ⟧W9⟧⟧W10⟧Measuring length: 0° … 360°, programmable⟧W11⟧⟧W12⟧Minimum measuring range: ? 35°⟧W13⟧⟧W14⟧Accuracy: ± 0.2% in in relation to the programmed angle ⟧W15⟧⟧W16⟧Communication interface: Analog⟧W17⟧⟧W18⟧Communication interface, detailed description: Voltage⟧W19⟧⟧W20⟧Connection type: Cable, radial, 1.5 m⟧W21⟧
⟧W22⟧Supply voltage: 19 … 33 V DC⟧W23⟧⟧W24⟧Current consumption: ⟧W25⟧⟧W26⟧Polarity inversion protection: ?⟧W27⟧⟧W28⟧MTTFd: time to life expectancy: 900 years (EN ISO 13849-1) ⟧W29⟧⟧W30⟧Electrical version: 3-core cable⟧W31⟧⟧W32⟧Mechanical version: Solid shaft, Servo flange⟧W33⟧⟧W34⟧Diameter shaft: 6 mm⟧W35⟧⟧W36⟧Shaft length: 12.4 mm⟧W37⟧⟧W38⟧Weight: 0.1 kg⟧W39⟧⟧W40⟧Shaft material: Stainless steel 1.4305⟧W41⟧⟧W42⟧ li>Material, flange: AlMgSi⟧W43⟧⟧W44⟧Material, housing: AlMgSi⟧W45⟧⟧W46⟧Material, cable: PVC⟧W47⟧⟧W48⟧Starting torque: 0.5 Ncm⟧W49⟧⟧W50⟧ li>Operating torque: 0.2 Ncm⟧W51⟧⟧W52⟧Shaft load capacity: 20 N / axial, 40 N / radial, ⟧W53⟧⟧W54⟧Moment of inertia of the rotor: 10 gcmІ⟧W55⟧⟧W56⟧ li>Bearing life: 1 x 10^6 revolutions⟧W57⟧⟧W58⟧Angular acceleration: ? 500,000 rad/sІ⟧W59⟧⟧W60⟧Operating speed: ? 3,000 min?№⟧W61⟧⟧W62⟧ EMC: EN 61000-6-2, EN 61000-6-4, ⟧W63⟧⟧W64⟧Protection type: IP65⟧W65⟧⟧W66⟧Permissible relative humidity: 90%⟧W67⟧⟧W68⟧Operating range temperature: –30 °C … +80 °C⟧W69⟧⟧W70⟧Storage temperature range: –40 °C … +100 °C, unpacked⟧W71⟧⟧W72⟧Shock resistance: 25 g , 11 ms (EN 60068-2-27)⟧W73⟧⟧W74⟧Vibration resistance: 4 g, 5 Hz … 100 Hz (EN 60068-2-6)⟧W75⟧⟧W76⟧Parameterizable code characteristic: CW (clockwise) ⟧W77⟧⟧W78⟧Load resistance: ? 10 k?⟧W79⟧⟧W80⟧Number of pulses per revolution: 2501 … 5000 li>⟧W81⟧⟧W82⟧Mechanical version: solid shaft/servo flange ⟧W83⟧⟧W84⟧Shaft diameter: 6 mm ⟧W85⟧⟧W86⟧Category:Absolute encoders ⟧W87⟧⟧W88⟧Series:ACS/ACM36 ⟧W89⟧⟧W90⟧
