Used for cutting processes of aluminum, plastic and wooden profiles. •Hydro-Pneumatic cutting process •Secure cutting by the cover equipped with a safety sensor •Cutting speed adjustment based on the profile •Cutting at -67,5°, -45°, -30°, -22,5°, -15°, 0°, 15°, 22,5°, 30°, 45° •Increase in cutting capacity with mobile miter •Pneumatic vertical and horizontal clamps
Технические характеристики
CharacteristicsTechnologybladeMaterialfor aluminum, for plastics, for woodProduct handledfor aluminum profiles, for PVC profilesApplicationsfor industrial applications, for metal fabrication, for the automotive industry, for shipbuilding, for the plastics industryWorkpiece loadingmanual loadingConfigurationsingle-headOther characteristicsautomatic, with conveyor, with vacuum baseOperating pressure
Min.: 6 bar (87.02 psi)
Max.: 8 bar (116.03 psi)
Overall length
920 mm (36 in)
Overall width
1,230 mm (48 in)
Height
1,675 mm (66 in)
Weight
331 kg (729.73 lb)
