hs35f encoder are industrial encoders that provide high accuracy and resistance to external influences. They have an insulated through-hole shaft with a diameter of 0.375 to 1 inch, which prevents damage to bearings due to high shaft currents.
Datasheet:
- Supply voltage: 4.75…30 VDC
- Reverse polarity protection: Yes
- Consumption without load: ≤40 mA (24 VDC), ≤130 mA (4.75 VDC) + output load, max. 250 mA
- Number of pulses per revolution: 1024 … 80000
- Accuracy: ≤60 angular seconds
- Measurement method: Optical
- Output signal frequency: ≤300 kHz (TTL), ≤160 kHz (HTL)
- Output signals: A, B, Z + complementary, ½ cycle index with negative channel B
- Output stages: Line driver (TTL, 7272), push-pull (HTL, 7272)
- Short circuit protection: Yes
- Interference resistance: EN 61000-6-2
- Radiated interference: EN 61000-6-3
| HS35F 01024 H AB_C MI07 D E 062 7 T5 | 11142355 |
| HS35F 01024 H ABZ_ MI07 B E 050 5 T3 | 11128816 |
| HS35F 01024 H ABZC C012 B E M15 7 T1 | 11203377 |
| HS35F 01024 H ABZC C018 B E 062 5 T5 | 11196748 |
| HS35F 01024 H ABZC C024 B E 100 5 | 11084369 |
| HS35F 01024 H ABZC C024 B E 100 5 T5 | 11140696 |
| HS35F 01024 H ABZC C024 B E 100 7 T5 | 11167544 |
| HS35F 01024 H ABZC C118 D E 062 7 T5 | 11117611 |
| HS35F 01024 H ABZC MI10 B E 050 7 T5 | 11183819 |
| HS35F 01024 H ABZC MI10 B E 062 5 T3 | 11158712 |
| HS35F 01024 H ABZC MI10 B E 062 7 T3 | 11128130 |
| HS35F 01024 H ABZC MI10 B E 100 5 | 11126328 |
| HS35F 01024 H ABZC MI10 B E 100 5 T5 | 11081546 |
| HS35F 01024 H ABZC MI10 B E M15 7 T3 | 11179857 |
| HS35F 01024 H ABZC MI10 B E M20 7 T5 | 11168782 |
| HS35F 01024 H ABZC MI10 D E 062 5 T3 | 11145699 |
| HS35F 01024 H ABZC MI10 D E 062 7 T1 | 11158664 |
| HS35F 01024 H ABZC MI10 D E 087 5 T3 | 11116880 |
| HS35F 01024 H ABZC MI10 D E 100 5 T3 | 11102141 |
| HS35F 01024 T ABZC C012 B E M15 7 T1 | 11203378 |
| HS35F 01024 T ABZC MI10 B E 062 5 T5 | 11127171 |
| HS35F 01024 T ABZC MI10 B E 100 5 | 11076448 |
| HS35F 01024 T ABZC MI10 B E 100 5 T3 | 11219442 |
| HS35F 01024 T ABZC MI10 B E 100 7 | 11203294 |
| HS35F 01024 T ABZC MI10 B E M15 5 | 11148682 |
| HS35F 01024 T ABZC MI10 B E M18 5 T3 | 11146847 |
| HS35F 01024 T ABZC MI10 D E 100 5 T3 | 11159508 |
| HS35F 02000 T ABZC MI10 B E 100 5 | 11177683 |
| HS35F 02048 H ABZ_ MI07 B E 100 5 | 11146358 |
| HS35F 02048 H ABZC C018 B E 075 5 T3 | 11215247 |
| HS35F 02048 H ABZC MI10 B E 075 5 T3 | 11220660 |
| HS35F 02048 H ABZC MI10 B E 100 5 | 11102389 |
| HS35F 02048 T ABZC MI10 B E 100 5 T3 | 11120546 |
| HS35F 02048 T ABZC MI10 B E 100 7 T5 | 11240667 |
| HS35F 02048 T ABZC MI10 D E 050 7 T1 | 11136876 |
| HS35F 02500 H ABZ_ MI07 B E 062 7 T4 | 11172790 |
| HS35F 02500 H ABZ_ MI07 B E 100 7 | 11172915 |
| HS35F 03600 T ABZ_ MI07 B E 087 7 T4 | 11178766 |
| HS35F 03600 T ABZC MI10 B E 062 5 T5 | 11116489 |
| HS35F 03600 T ABZC MI10 B E 075 7 | 11167680 |
| HS35F 04096 T ABZ_ MI07 B E 100 5 T1 | 11163761 |
| HS35F 04096 T ABZC MI10 B E 075 5 T3 | 11181395 |
| HS35F 05000 H ABZ_ MI07 B E 100 7 T5 | 11156431 |
| HS35F 05000 H ABZC MI10 B E 100 5 | 11190279 |
| HS35F 05000 H ABZC MI10 B E 100 5 T5 | 11193077 |
| HS35F 05000 H ABZC MI10 B E 100 7 | 11110598 |
| HS35F 05000 H ABZC MI10 B E M14 5 | 11171477 |
| HS35F 05000 H ABZC MI10 D E 100 7 T5 | 11124273 |
| HS35F 05000 T ABZ_ MI07 B E M14 5 T3 | 11164999 |
| HS35F 08192 H ABZC MI10 D E 100 7 T3 | 11154851 |
| HS35F 08192 T ABZC MI10 B E 075 4 T5 | 11144191 |
| HS35F 08192 T ABZC MI10 B E 087 7 T3 | 11206222 |
| HS35F 10000 H ABZC C012 B E 100 5 T1 | 11200751 |
| HS35F 10000 H ABZC MI10 D E 100 5 T5 | 11205876 |
| HS35F 10000 T ABZC C024.B E 100 5 T5 | 11232262 |
| HS35F 10000 T ABZC MI10 B E 075 5 | 11159014 |
| HS35F 10000 T ABZC MI10 B E 100 5 | 11143167 |
| HS35F 10000 T ABZC MI10 D E 100 5 T5 | 11174661 |
| HS35F 15000 T ABZ_ C024 B E 100 5 | 11100900 |
| HS35F 16384 H ABZ_ MI07 B E M20 7 T3 | 11187862 |
| HS35F 16384 T ABZ_ MI07 B E 100 5 | 11153242 |
| HS35F 20000 H ABZC MI10 B E 100 5 T3 | 11243432 |
| HS35F 20000 T ABZC MI10 B E 100 4 T1 | 11194947 |
| HS35F 20000 T ABZC MI10 B E 100 4 T3 | 11214603 |
| HS35F 20000 T ABZC MI10 B E 100 4 T5 | 11204315 |
| HS35F 25000 H ABZC MI10 B E 050 5 | 11199602 |
| HS35F 40000 H ABZ_ C018 B E M20 5 T3 | 11153694 |
| HS35F 40000 T ABZC MI10 B E M20 5 T3 | 11190578 |
| HS35F 80000 T ABZ_ MI07 B E 075 5 T4 | 11117242 |
| HS35F 80000 T ABZ_ MI07 B E 100 7 T5 | 11173078 |
| HS35F 80000 T ABZ_ MI07 B E M20 5 T5 | 11207830 |
| HS35F 80000 T ABZC C024 B E 075 7 T4 | 11172958 |
| HS35F 80000 T ABZC MI10 B E M12 5 T3 | 11215507 |
| HS35F 80000 T ABZC MI10 B E M15 7 T3 | 11160694 |
