| housing material | die-cast zinc |
| current consumption max. (no load) | 41 mA |
| depth | 50 mm |
| protection class | IP 67 |
| front (optics) | PMMA |
| light indicator | LED yellow |
| operating temperature | -25 … +65 °C |
| sensing distance Tw | 0 … 400 mm |
| connection types | connector M12 4 pin |
| voltage supply range +Vs | 10 … 30 VDC |
| reverse polarity protection | yes |
| suppression of reciprocal influence | yes |
| voltage drop Vd | |
| output circuit | PNP |
| current consumption typ. | 29 mA |
| short circuit protection | yes |
| wave length | 880 nm |
| output current | |
| response time / release time | |
| manufacter SKU | FZDM 16P5101/S14 |
| light source | pulsed infrared diode |
| output function | light / dark operate |
| type | rectangular |
| width / diameter | 15,4 mm |
| sensitivity adjustment | potentiometer, 270° |
| height / length | 50 mm |
| type | intensity difference |
| alignment / soiled lens indicator | flashing light indicator |
