| voltage supply range +Vs | 10 … 30 VDC |
| width / diameter | 15,4 mm |
| type | rectangular |
| polarization filter | yes |
| reverse polarity protection | yes |
| output circuit | PNP |
| height / length | 50 mm |
| current consumption typ. | 26 mA |
| response time / release time | < 1 ms |
| housing material | die-cast zinc |
| current consumption max. (no load) | 36 mA |
| protection class | IP 67 |
| short circuit protection | yes |
| actual range Sb | 7,3 m |
| output current | < 200 mA |
| operating temperature | -25 … +65 °C |
| manufacter SKU | FPDM 16P5101/S14 |
| light indicator | LED yellow |
| depth | 50 mm |
| sensitivity adjustment | no |
| wave length | 660 nm |
| light source | pulsed red LED |
| nominal range Sn | 8,5 m |
| connection types | connector M12 4 pin |
| front (optics) | PMMA |
| alignment / soiled lens indicator | flashing light indicator |
| voltage drop Vd | < 1,8 VDC |
| output function | light / dark operate |
| suppression of reciprocal influence | yes |
| type | retro-reflective sensor |
