| sensitivity adjustment | Teach-in |
| suppression of reciprocal influence | yes |
| front (optics) | PMMA |
| protection class | IP 65 |
| wave length | 660 nm |
| light indicator | LED green |
| manufacter SKU | FPDK 07P6901/KS35A |
| voltage supply range +Vs | 10 … 30 VDC |
| height / length | 17,8 mm |
| actual range Sb | 0,6 m |
| housing material | plastic (PMMA, MABS, PA) |
| output circuit | PNP |
| response time / release time | |
| connection types | flylead connector M8 4 pin, L=200 mm |
| depth | 12,6 mm |
| polarization filter | yes |
| current consumption typ. | 20 mA |
| output current | |
| operating temperature | -20 … +50 °C |
| type | retro-reflective sensor |
| nominal range Sn | 0,8 m |
| current consumption max. (no load) | 25 mA |
| output indicator | LED yellow |
| type | rectangular |
| light source | pulsed red LED |
| width / diameter | 8 mm |
| short circuit protection | yes |
| reverse polarity protection | yes |
| alignment / soiled lens indicator | flashing light indicator |
| voltage drop Vd | |
| output function | light / dark operate |
Buy Baumer FPDK 07P6901/KS35A with the best possible price and delivery terms on eltra-trade.com
Eltra Trade s.r.o. offers factory automation products. We can offer you specific products which are not available from other suppliers. We provide delivery to all continents. We can give you a quick response and very good prices. We always communicate openly with our clients. We provide a personal approach to each client.
